6JRXM-2 Space & MIL-Spec Relay

  • This relay is the first generation of sealing products of China’s innovative miniaturization series. It has been improved by reliability, and the technical indicators conform to the GJB65B general specification and GJB65/10- 2011 single specification requirements. The design specifications of the products are large in size, compact in structure and high in inherent reliability. After long-term and large-scale testing for various models, they can work reliably under harsh environmental conditions. It can be used for aerospace, aviation and ground equipment automatic control systems for transmitting signals and switching circuits.
Category:

6JRXM-2 Small General-Purpose Relay

Environmental Characteristics

No.

 Parameter Environmental Specification

1

 Quality Grade Ⓙ, G G+ GJB J/K

II

2

 Temperature Range (℃) -55~85 -65~105

3

 Relative Humidity (40±2) ℃, 90%~95%

4

 Low Pressure (kPa) 0.67~0.27

4.39
5 Sinusoidal Vibration (Hz)

10~2000
(m/s2) 150 147

196
6 Random vibration (m/s2)2/Hz — 10

25
7 Shock (m/s2) 500 490

735
8 Constant Acceleration (m/s2) 500 490

735



Main Characteristics

(The following table list GJB, J / K product indicators, other quality levels, please refer to their respective specifications)

Contact Arrangement

 6 PDT Operating Time (ms) ≤10

Coil Power (W)

 3.14 Release Time (ms) ≤5

Leak Rate (Pa.cm3/s)

 ≤1×10-2 Load Ratings Resistive 2A, 28V d.c.

Contact Resistance(Ω)

 Initial ≤0.05 Inductive 0.3A, 28V d.c.,200mH

After Life

 ≤0.1 lamp 0.1A, 28V d.c.
Insulation Resistance (MΩ) Normal ≥10000(100Vd.c.) Low level

10~50 µA, 10mV~50mV
High Temp./Humidity ≥100(100Vd.c.) Life Time (Cycles)

1×105
Dielectric Strength

(50Hz)

 Normal

≥500
Low pressure ≥350 Overload rating

Resistive, 4A, 28V d.c.
Weight (g) ≤42 failure rate

M level



Electrical Specification

Specification No.

 Coil Voltage 25℃ Overall Temperature Range

Normal

 Max Coil resistance (Ω)

(1±10%) Ω

 Operating Voltage max Release Voltage (min) Operating Voltage max

Release Voltage (min)
028 28 30 250 16 2 23

1



Dimensions
6JRXM 2 Mounting Style A 0 6JRXM 2 Mounting Style D 4 6JRXM 2 Mounting Style C 2
Mounting Style A (0) Mounting Style D (4) Mounting Style C (2)
Note: Vibration sensitive direction: Horizontal



Circuit Diagram

Resistive Load Diagram
6JRXM 2 Circuit Diagram 6JRXM 2 Resistive Load Diagram



Order Mark

  • National military standard product:

Example: J65 / RY20009-028 L/22 6JRXM-2

J 65 / RY20009 – 028 L / 2 2 6JRXM-2
Military sign General specification number Detailed specification number Coil voltage Failure rate Mounting style Terminal form Product number

Detailed specification: Q/RY20016-2002



  • J/K grade product:

Example: J65 / RY20056-028 M/22 6JRXM-2

J 65 / RY20056 – 028 M / 2 2 6JRXM-2
Military sign General specification number Detailed specification number Coil voltage Failure rate Mounting style Terminal form Product number

Detailed specification: Q/RY20054-2003



  • G+ grade military product:

Example: 6JRXM-2/II 28 C

6JRXM-2 / II 28 C
Product number Environmental rating Coil voltage Mounting style

Detailed specification： Q/RYJ0133A-99



  • G grade military product:

Example: 6JRXM-2/II 28 C

6JRXM-2 / II 28 C
Product number Environmental rating Coil voltage Mounting style

Detailed specification: Q/RYJ0104-90
