Environmental Characteristics
| Environmental Specifications | ||
| Temperature Range | (℃) | -65~+125 |
| Relative Humidity | (40±2) ℃, 90%~95% | |
| Vibration | (Hz) | 10~3000 |
| (m/s2) | 294 | |
| Random Vibration | (m/s2)2/Hz) | 40 |
| Shock | (m/s2) | 735 |
| Acceleration | (m/s2) | 735 |
Electrical Characteristics
| Contact Arrangement | DPDT | Operate Time (ms) | ≤4.0 | ||
| Coil Operating Power (W) | 0.5 | Release Time (ms) | ≤3.0 | ||
| Leak Rate (atm.cm3/s) | ≤1 X 10-9 | Contact Load Ratings | Resistive | 1.0A, 28V d.c. | |
| Contact Resistance (Ω) | Initial | ≤0.1 | |||
| After life | ≤0.2 | ||||
| Insulation Resistance (MΩ) | 25℃ | ≥10000 (500V d.c.) | Low level | 10µA~50µA, 10mV~50mV | |
| 125℃ | ≥1000 (500Vd.c.) | ||||
| Dielectric Strength Vr.m.s.(50Hz) | Normal | ≥500 | |||
| Low pressure | ≥125 | Contact Life Ratings | 1 X 105Cycles | ||
| Mass (g) | ≤2.55 | Contact Overload Rating | DC, 2.0A, 28V d.c., 100 Cycles | ||
Detailed Electrical Specifications (-65°C to 125°C) Vd.c.
| Coil Code | Coil Voltage | 25℃ | -65℃ to 125℃ | ||||
| Nominal | Maximum | Coil Resistance (1±10%) Ω | Pick-up Voltage max | Drop-out Voltage min | Pick-up Voltage max | Drop-out Voltage min | |
| 005 | 5 | 5.8 | 50 | 2.7 | 0.22 | 3.5 | 0.14 |
| 012 | 12 | 16.0 | 390 | 7.0 | 0.63 | 9.0 | 0.41 |
| 027 | 27 | 32.0 | 1560 | 14.2 | 1.37 | 18.0 | 0.89 |
Dimensions |
Connection Diagram |
Resistive Load |
 |
 |
 |
RF Parameters
| Parameters | Unit | Target |
| Frequency | GHz | 0.05 -5 |
| Insertion Loss | (dB) | ≤1.0 |
| Isolation | (dB) | ≥20 |
| VSWR | - | ≤1.9 |
Order mark
Example: J65B/XP30008-027JPW-220M
| J | 65B | / | XP30008 | – | 027 | JWP-220M |
| Relay Series | Coil Code | Detailed Specification Number | Specification Number | Style Symbol |
